The model number and serial number for your Kamado Joe grill can be found in the owner’s manual that comes included with your grill. You can also locate the serial number and date code found on a red sticker on the back of the base of your unit.

For Konnected Joe units this can be found on the metal plate on the back of the unit.

MATERIALS: Ensure the materials used are non-combustible and can handle high temperatures.

BASE: Ensure the Kamado Joe ceramic feet are used to create an air gap underneath the base of the grill. Do NOT place the grill directly on the table surface without an air gap.

ACCESS: Ensure there is front access so that the Ash Drawer is not blocked.

CLEARANCE: Ensure there is space between the top of the table and the edge of the grill. The table top SHOULD NOT make direct contact with the grill.

Please use this as a general guide for installing your Kamado Joe into a built-in outdoor kitchen or grill table.

We highly recommend that the actual grill being installed be measured.

Drawing is not to scale.

Check the Documents & Files section for the Built-In Guide.

MATERIALS: Ensure the materials used are non-combustible and can handle high temperatures.

BASE: Ensure there is a hole directly underneath the grill to allow cool air to reach the bottom of the grill. Use caution, sparks and hot ash can reach the bottom of the grill.

*Konnected Joe hole size: 12.25 inches (32cm) in diameter
*Big Joe Konnected Joe hole size: 16.5 inches (42 cm) in diameter

Note: the Kamado Joe ceramic feet are not to be used in absence of the hole under the grill. The hole is required and the ceramic feet are NOT compatible with Konnected Joe.

ACCESS: Ensure there is rear access to the main power switch. Ensure there is front access so that the Kontrol Board or Ash Drawer are not blocked.

CLEARANCE: Ensure there is space between the top of the table and the edge of the grill. The table top SHOULD NOT make direct contact with the grill.

Please use this as a general guide for installing your Konnected Joe into a built-in outdoor kitchen or grill table. We highly recommend that the actual grill being installed be measured. Drawing is not to scale.

Table should be fixed on the ground or wall. Non-flammable building materials are required for construction.

Checked product's Documents & Files section for the downloadable guides.

Table should be fixed on the ground or wall. Non-flammable building materials are required for construction.

The Konnected Joe is the very first Kamado Joe grill to offer built-in digital controls to provide a digitally connected ceramic grilling experience. Light your charcoal with the push of a button and control and monitor your cooks via the Kontrol Board or the Kamado Joe app. The Konnected Joe also offers the standard Kamado Joe innovation with the 2-Tier Divide & Conquer® Cooking System, Slide-Out Ash Drawer, Air Lift™ Hinge and more.

The Konnected Joe is available in two sizes: 18-inch and Big Joe 24 inch.

1. The Automatic Fire Starter (AFS) ignites charcoal quickly with the push of a button via heating element inside the grill.
2. Kontrol Board™ allows the user to set and monitor cook modes, grill temperature, meat probes, and session graphing. Connect to the Kamado Joe app via WiFi.
3. The Digital Fan maintains and regulates temperature consistency throughout the cook by generating airflow through the grill interior. You may also use Classic Cook mode for a traditional Kamado Joe grilling experience.

Both sizes of the Konnected Joe™ will come standard with the 2-Tier Divide & Conquer Flexible Cooking System, folding aluminum side shelves, heavy-duty powder-coated steel grill cart, 2 ceramic heat deflectors, 2 stainless steel cooking grates, ash tool, grill gripper, and 1 meat probe.

The original 46 cm Konnected Joe is compatible with most Classic Joe series sized accessories (Classic Joe Charcoal Basket NOT compatible with the Konnected Joe grill).

The 61 cm Big Joe Konnected Joe is compatible with most Big Joe series sized accessories (Big Joe Charcoal Basket NOT compatible with the Big Joe Konnected Joe grill).

Yes, the Konnected Joe can be built into an outdoor kitchen. Simply remove the screws from the cart and use your product as a standalone grill. See manual for instructions.

The Konnected Joe can sear at high heats up to 700° F or cook low and slow at 225°F temperatures.

Use the official Kamado Joe App in order to set your grill temperature, cooking times and discovering

• Download on the App Store (iOS)

• Get it on Google Play (Android)

1. Joe Jr Cart with Shelves
2. Stainless Steel Cooking Grate for Joe Jr (KJ-CG13)
3. Cast Iron Fire Grate for Joe Jr (KJ-MFG13)
4. Kamado Joe Sear Plate
5. Joe Jr Cover

The cart is made from heavy-duty powder coated steel so it can withstand the elements.

The cart raises the cooking height of the Joe Jr to 31 inches off the ground.

3 shelves – two folding side shelves with tool hooks and a bottom shelf large enough for all Joe Jr cooking accessories.

Yes, the Joe Jr Cover (KJ15080420) is compatible even with your Joe Jr installed into the cart!

Does not work with JoeTisserie or Divide & Conquer cooking system.

Compatible Accessories

1. KJ-HCICG – Cast iron grate
2. KJ-HCIGRIDDLE – Cast iron reversible griddle
3. KJ-HCGSSTONE – Soapstone cooking surface
4. KJ-SCS – Grill expander
5. KJ-PS23 – Pizza Stone
6. KJ-HCG – Standard half grate
7. KJ-HSSCGFV – Stainless steel cooking surface
8. KJ-GC23BWFS – Kamado Classic Grill Cover
9. Kamado DoJoe

1. Our Big Joe Heat Deflectors can be used on the lower tier of the cooking rack.
2. All Classic Joe cooking surfaces will fit on top of the firebox.
3. Kettle Joe Cover (KJ15080320)

* The Joetisserie and DoJoe are not compatible with this unit.

1. An ash drawer gives you an easy, quick clean up compared to other kettle grills.
2. We always recommend you protect your grill with a cover, but the coating on the grill will prevent it from rusting. It will only rust if the porcelain coating chips.
3. Features our standard KJ Warranty.

Our Classic and Big Joe grill bodies are entirely made of ceramic, while the Kettle Joe has ceramic inserts, but a traditional kettle body made up of steel. The Kettle Joe features a ceramic firebox for improved heat  retention and durability.

Need help stacking your charcoal? We’ve got you covered with the helpful video on the Videos section.

Controlling the temperature on your new Kamado Joe grill is one of the most important aspects of ceramic grill cooking, and check the helpful video outlines just how to do that on the Videos section.

1. Distance: Learn about the fundamentals of distance on the Kamado Joe in our Videos section - The Fundamentals: Distance.
2. Fire: Fire is the main cooking element for our grill, learn how to handle it in our Videos section - The Fundamentals: Fire.
3. Surfaces: The cooking surface has the ability to alter how you cook, and different foods will call for different surfaces. Learn all about how to use cooking surfaces on your Kamado Joe grill in our Videos section - The Fundamentals: Surfaces.
4. Smoke:  Smoke is flavor’s best friend. Learn how to harness the power of smoke when cooking on your Kamado Joe grill in our Videos section - The Fundamentals: Smoke.

Check our Videos section for: How to Light Your Kamado Joe Grill
Check our Videos section for: How To Cool Down Your Kamado Joe Grill

Gaps between the firebox walls of your Kamado Joe are caused by normal expansion and contraction from heat. While they may look concerning, as long as the gaps aren't causing performance issues, it's usually not a major concern. Remember, with proper registration, should any issue arise, our friendly and knowledgeable customer service agents are happy to take a look.

Check our Videos section for: Introduction to SlōRoller
